AE 2P 80A Smart ATS for Solar Inverter | PV System Automatic Transfer Switch | 2P Dual Power Selector with Intelligent Controller | DIN Rail Mount

☀️ Intelligent Energy Management for Your Solar Home

• Smart Controller: Built-in microprocessor for intelligent power source prioritization.

• 80A Capacity: Perfect for residential solar systems, inverters, and backup loads.

• Solar Priority Mode: Automatically uses PV/battery power first, grid as backup.

• 2P Isolation: Switches Live + Neutral for complete safety.

• DIN Rail Mount: Clean, space-saving installation in any distribution board.

  Technical Specifications

  Specification	Detail
  Model	ATS-SMART-80A-2P
  Type	Intelligent Automatic Transfer Switch
  Rated Current	80 Amps
  Rated Voltage	230V AC (50/60Hz) / 110V AC versions available
  Poles	2P (Switches L & N)
  Controller	Microprocessor-based, programmable
  Mounting	35mm DIN Rail
  Display	LED Indicators for Source Status
  Programmable Settings	Voltage limits (160V-280V), Time delays (0-999s)
  Transfer Time	< 3 seconds (adjustable)
  Generator Start	Dry contact output (optional)
  Terminal Capacity	Up to 25mm²
  Operating Temperature	-10°C to +55°C
  Certification	CE
