ATS 110V 125A 2P Automatic Transfer Switch | DIN Rail Dual Power Changeover for Solar/City Power/Generator | Uninterrupted Power Supply for Home & Off-Grid Systems

⚡ Automatic Power Switching for 110V Systems – Never Lose Power Again

• 125A High Capacity: Handles whole-house loads, workshops, and large appliances.

• 2P Safety Design: Switches Live + Neutral for complete isolation.

• Tri-Source Compatible: Seamlessly switch between Solar, City Power, and Generator.

• DIN Rail Mount: Easy installation in standard electrical panels.

• Uninterrupted Operation: Automatic transfer ensures continuous power to critical loads.

  Technical Specifications

  Specification	Detail
  Model	ATS-110V-125A-2P
  Type	Automatic Transfer Switch
  Rated Current	125 Amps
  Rated Voltage	110V AC (120V compatible, 60Hz)
  Poles	2P (Switches L + N)
  Mounting	35mm DIN Rail
  Transfer Time	< 3 seconds (adjustable)
  Delay Settings	Transfer delay: 0-30 sec / Return delay: 0-30 min
  Voltage Monitoring	Under/over voltage protection
  Generator Start	Dry contact output (optional)
  Terminal Capacity	Up to 2 AWG (35mm²)
  Electrical Life	> 3,000 operations
  Mechanical Life	> 10,000 operations
  Operating Temperature	-5°C to +40°C
  Enclosure Material	Flame-retardant PC/ABS (UL94 V-0)
  Certification	CE
